Air handling units
for healthcare sites
ECE UK are one of the most highly regarded air handling unit manufacturers in the UK, serving healthcare sites with bespoke solutions to their ventilation and air conditioning needs. A custom air handling unit is a sophisticated way to optimise your healthcare site’s indoor air quality, which is essential to sustainably boosting health and wellbeing. Clean and conditioned air is vital to the long-term functionality of any healthcare facility, from protecting sensitive areas like operating theatres to maintaining the comfort of patients and the productivity of staff. We are highly experienced at working with site managers, ventilation safety groups, contractors, and consultants at healthcare sites across the UK. Our design engineers create bespoke systems that meet the exact needs of every part of your site, from operating theatres to palliative care to administration. We ensure that every space will be served with air that has been cleaned and conditioned in line with your requirements and government regulations.
Get your
custom AHU
We specialise in delivering fully bespoke solutions for your healthcare site. Contact our team and begin the design process by calling 01634 729 690, sending an email to sales@eceuk.com, or filling out our contact form.
How will we create your air
handling system?
Planning and advice
Our team will conduct a free site survey and assess the relevant legislation and regulations surrounding indoor air quality and ventilation. From there we give comprehensive advice and guidance on the design implications, legality, maintenance requirements, and operation of a specialised air handling unit.
1
Fully custom design
Every component is designed down to the millimetre to fit the space at your site. Our design engineers are highly experienced and work with building information modelling and site teams to reconcile the unique needs of healthcare sites with their space restrictions.
3
Ongoing support
We offer service and maintenance packages that will help extend the lifespan of your AHU and resolve any potential issues quickly and efficiently. Our in-house technicians will use their familiarity with your system to deliver an effective and efficient service every time.
5
Identify air quality
We use the highly specific data provided by the Department for Environment, Food, and Rural Affairs (DEFRA) to identify the air quality at your location’s post code. This lets us select the appropriate supply air category and filter classification in accordance with SVHSoc.02 Classification, BS EN 16798-3:2017 and BS EN 16890:2016.
2
Professional installation
Our technicians can deliver and install every part of your air handling system. We ensure that there is safe access for cleaning and maintenance so your unit will maintain its efficacy without clogging or slowing down. This ensures the safe operation of your air handling unit, eliminating the possibility of airborne pathogens and contaminants.
4
The importance of indoor air quality in healthcare
There is an increasing awareness surrounding the significance of indoor air quality in the healthcare industry. The Royal College of Paediatrics and Child Health and the World Health Organisation have both published studies on the importance of air quality for the good health of both the building and its occupants. Critical parts of a healthcare facility such as operating theatres, laboratories, and pharmaceutical production suites require a superior level of indoor air quality to remove airborne microorganisms that can cause severe infection in patients or contaminate samples. It is estimated that as many as 25% of infections that result from surgery are caused by airborne particulates making it clear how essential proper air circulation is. Conventional air conditioning systems provide between four and eight air changes per hour, replacing stale and contaminated air with clean, fresh air. A custom designed and professionally manufactured system from ECE UK can change the air as often as ninety times per hour, making it a vital tool to reduce the risk to patients and increase health and wellbeing at your facility.
Get started today
Make sure that your healthcare site receives an effective and lasting air handling and ventilation solution. We are the team to choose to provide advanced health and wellbeing benefits at your site and help protect your patients and staff. Get in touch today and speak to one of our design engineers by calling 01634 729 690, sending an email to sales@eceuk.com, or leaving an enquiry via our form.
The ideal air handling units for your healthcare needs
We provide a range of AHUs with different functions that can all be customised to suit the exact needs of the different areas of your site. Our experienced technicians will work carefully with your engineers to create a bespoke solution. We’d recommend the following units for a healthcare facility and can help select the right one for the right space. We will further tailor each unit to your site’s specific needs.
RAC
This unit keeps the heat recovery and extract air streams completely separate. This is vital for a sensitive healthcare environment such as an operating theatre, as there is no way for the extract air to contaminate the supply air. This ensures a cleaner indoor environment for patients.
PXA
The supply and extract air are kept distinct by a plate recuperator which captures heat from the extracted air and uses it to warm the supply, preserving heat and energy. This plate has been tested to be 100% leak free, so you can rely on reduced cross contamination and a more hygienic environment.
RXA
These AHUs are classified as regenerators due to their rotating carrier. The carrier rotates between the supply and extract air streams to recover the energy from the extract and pass it over to the supply. The RXA does include a purge sector that reduces leakage from the extracted air to the supply but is still best suited to non-critical areas such as administration.
SSAU
Ideal for spaces which only require supply air, this unit recirculates secondary and fresh air back into a positively pressured area like a clean room or pharmaceutical suite. Multi-stage filtration including HEPA can be used with this AHU with 99.995% filtration efficiency at 0.3 microns.
SU
This unit provides supply air for ventilation systems and has a separate extract which can be connected to a fume cupboard to remove harmful substances from laboratories. This AHU can be fitted with multi-stage filtration including HEPA to provide 99.995% filtration efficiency at 0.3 microns.
Every single AHU in our range has the option for single or multi-stage filtration to suit the requirements of the space it is ventilating. Depending on your needs, your AHU could include anything from a single fine filter to a four-stage filtration system that includes a coarse filter, fine filter, carbon filter, and a high-efficiency particulate absorbing (HEPA) filter. At this high level of filtration, your air handling unit can provide cumulative efficiency of as much as 99.99965%.
Achieving net zero carbon through air management
In 2020, NHS England laid out a road map towards becoming the first net zero national health service in the world by the year 2045, with its Welsh and Scottish counterparts making similar pledges afterwards. Part of what will make these goals possible is intelligently designed air handling units and ventilation systems that can capture and recycle heat while still providing clean and uncontaminated air. At ECE UK, our team are committed to helping the NHS achieve their carbon goals by installing this highly effective equipment at healthcare facilities across the country.
Why choose ECE UK for
your healthcare AHU?
With decades of experience in the industry, a sophisticated design process, and in-house manufacturing within our own factory in Kent, ECE UK are one of the leading AHU companies in the country. We’ve developed a sophisticated process and cultivated an expert team that puts your needs first.
Knowledgeable
Working with ECE UK means that you’ll have access to our expert team and the vast wealth of knowledge we’ve accumulated over the years we’ve spent in the industry. We are always looking for new ways to increase our team’s knowledge and facilitate internal collaboration. This ensures that every department is working in unison to deliver the very best solution for our clients.
Experienced
ECE UK is a family run business that has been successfully providing the nation with sophisticated air handling units since 1979. With four decades of history and multiple generations working in our team, we can not only draw on our experience, but also encourage newcomers to help us innovate and push the company to even greater heights.
Skilled
We have the capabilities to design your AHU down to the millimetre to meet your requirements. We’ve brought as much of the process in-house as possible so that you can rely on the skill and expertise that has earned us our reputation. We can reduce lead times and deliver more unique and useful solutions faster than other manufacturers.
Get in touch with ECE UK
Reach out to our team and begin your journey towards a fully customised air handling unit for your healthcare site. Just call 01634 729 690 or send an email to sales@eceuk.com to get started.
